CM150DU-24F

Mitsubishi CM150DU-24F

#CM150DU-24F Mitsubishi CM150DU-24F New 150A/1200V/IGBT/2U;IGBT MOD DUAL 1200V 150A F SER , CM150DU-24F pictures, CM150DU-24F price, #CM150DU-24F supplier
——————————————————————-
Email: sales@shunlongwei.com

——————————————————————-

CM150DU-24F
Category Discrete Semiconductor Products
Family IGBTs – Modules
Manufacturer : Powerex Inc.
Series IGBT MOD™
IGBT Type Trench
Configuration Half Bridge
voltage – Collector Emitter Breakdown (Max) 1200V
Current – Collector (IC) (Max) 150A
Power – Max 600W
Vce(on) (Max) @ Vge, IC 2.4V @ 15V, 150A
Current – Collector Cutoff (Max) 1mA
Input Capacitance (Cies) @ Vce 59nF @ 10V
Input Standard
NTC Thermistor No
Mounting Type Chassis Mount
Package / Case Module
Supplier Device Package Module


150A/1200V/IGBT/2U;IGBT MOD DUAL 1200V 150A F SER

Share:

Saturday, May 29, 2021

G084SN05 V3

AUO G084SN05 V3

#G084SN05 V3 AUO G084SN05 V3 New AUO 8.4inch Panel 800×600 500:1 262K CCFL LVDS , G084SN05 V3 pictures, G084SN05 V3 price, #G084SN05 V3 supplier
——————————————————————-
Email: sales@shunlongwei.com sales[email protected]

——————————————————————-


Panel Brand : AUO
Panel Model : G084SN05 V3
Panel Type : a-Si TFT- LCD , Panel
Panel Size : 8.4 inch
Resolution : 800(RGB)×600 , SVGA
Display Mode : TN, Normally White, Transmissive
Active Area : 170.4×127.8 mm
Outline : 203×142.5 mm
Brightness : 450 cd/m² (Typ.)
Contrast Ratio : 500:1 (Typ.)
Display Colors : 262K   (6-bit)
Response Time : 10/25 (Typ.)(Tr/Td)
Viewing Angle : 60/60/60/40 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 2 pcs CCFL
Signal Interface : LVDS (1 ch, 6-bit)
Input voltage : 3.3V (Typ.)

Share:

FP40R12KT3

Eupec FP40R12KT3

#FP40R12KT3 Eupec FP40R12KT3 New IGBT Modules N-CH 1.2KV 55A, FP40R12KT3 pictures, FP40R12KT3 price, #FP40R12KT3 supplier
——————————————————————-
Email: sales@shunlongwei.com [email protected]

——————————————————————-

FP40R12KT3 FP40R12KT3
Manufacturer: Infineon
Product Category: IGBT Modules
RoHS: YES
Product: IGBT Silicon Modules
Configuration: Hex
Collector- Emitter voltage VCEO Max: 1200 V
Continuous Collector Current at 25 C: 55 A
Maximum Operating Temperature: + 125 C
Package / Case: Econo 2
Packaging: Tray
Brand: Infineon Technologies
Maximum Gate Emitter Voltage: +/- 20 V
Minimum Operating Temperature: – 40 C
Mounting Style: Screw
Factory Pack Quantity: 10


IGBT Modules N-CH 1.2KV 55A

Share:

BSM15GD120DN2E3224

Eupec BSM15GD120DN2E3224

#BSM15GD120DN2E3224 Eupec BSM15GD120DN2E3224 New IGBT Modules N-CH 1.2KV 25A , BSM15GD120DN2E3224 pictures, BSM15GD120DN2E3224 price, #BSM15GD120DN2E3224 supplier
——————————————————————-
Email: sales@shunlongwei.com

——————————————————————-

BSM15GD120DN2E3224
Manufacturer: Infineon
Product Category: IGBT Modules
RoHS: YES
Product: IGBT Silicon Modules
Configuration: Hex
Collector- Emitter voltage VCEO Max: 1200 V
Collector-Emitter Saturation Voltage: 2.5 V
Continuous Collector Current at 25 C: 25 A
Gate-Emitter Leakage Current: 150 nA
Maximum Operating Temperature: + 150 C
Package / Case: EconoPACK 2
Brand: Infineon Technologies
Maximum Gate Emitter Voltage: 20 V
Minimum Operating Temperature: – 40 C
Mounting Style: Screw
Pd – Power Dissipation: 145 W
Factory Pack Quantity: 10

IGBT Modules N-CH 1.2KV 25A

Share:

Mitsubishi CM50MD-12H

Mitsubishi CM50MD-12H Technical Infomation

#CM50MD-12H Mitsubishi CM50MD-12H New PIM: 50A600V, CM50MD-12H pictures, CM50MD-12H price, #CM50MD-12H supplier

CM50MD-12H Description

IGBT Power Module, CIB Module Three Phase Converter Three Phase Inverter Brake 50 Amperes/600 Volts, IGBT POWER TRANSISTOR MODULES MEDIUM POWER SWITCHING USE INSULATED TYPE

CM50MD-12H  0.22 lbs

Target_Applications

CM50MD-12H could be used in AC & DC motor controls, General purpose inverters, Servo drives, NC, Robotics

Features

IGBT POWER TRANSISTOR MODULE
PIM: 50A600V

Share:

AUO G121XN01 V1

AUO G121XN01 V1

#G121XN01 V1 AUO G121XN01 V1 New G121XN01 V1 AUO 12.1″ LCM 1024×768 500 700:1 80/80/80/80 16.7M WLED eDP, G121XN01 V1 pictures, G121XN01 V1 price, #G121XN01 V1 supplier

Brand AUO
Model G121XN01 V1
Diagonal Size 12.1 inch
Type a-Si TFT-LCD, LCM
Pixel Format 1024(2)×768(2)  [XGA]  105PPI
Configuration RGBW Rectangle
Active Area 245.76(H)×184.32(V) mm
Luminance 500 cd/m² (Typ.)
Contrast Ratio 700:1 (Typ.) (TM)
Response Time 25/10 (Typ.)(Tr/Td)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down
Operating Mode TN, Normally White, Transmissive
Support Color 16.7M   72% NTSC
Light Source WLED , 50K hours
Designed For Industrial
Frame Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Panel Without
Interface Type eDP
Environment Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C
