AUO G156HTN02.1

AUO G156HTN02.1
#G156HTN02.1 AUO G156HTN02.1 New a-Si TFT-LCD 15.6-inch 1920×1080 400nit 700:1 (Typ.) 16.7M colors 60Hz WLED LVDS (2 ch, 8-bit), G156HTN02.1 pictures, G156HTN02.1 price, #G156HTN02.1 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Manufacturer AUO Model Name G156HTN02.1
Screen Size 15.6 inch  Screen Type  LCM,   a-Si TFT-LCD
Pixel Number 1920(RGB)×1080   (FHD)  Arrangement RGB Vertical Stripe
Active Area(mm) 344.16 × 193.59 (H×V) Outline(mm) 363.8 × 215.9 × 12.5 (H×V×D)
Bezel Area(mm) 347.06 × 196.49 (H×V) Treatment Antiglare (Haze 25%), Hard coating (3H)
Luminance 400 cd/m² (Typ.) Contrast Ratio 700 : 1 (Typ.) (TM)
Viewing Angle 70/70/60/60 (Typ.)(CR≥10) Left / Right / Up / DownResponse8 (Typ.)(Tr+Td) ms
Work Mode TN, Normally White, Transmissive
Color Depth 16.7M   72% NTS CBacklight WLED , 50K hours , With LED Driver
Mass 1.04W (Max.) Used forIndustrial
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit Touch screen Without
Signal TypeLVDS (2 ch, 8-bit) , Connector , 30 pins
Voltage Supply3.3V (Typ.)
Max. RatingsStorage Temp.: -20 ~ 70 °C    Operating Temp.: -10 ~ 70 °C
G156HTN02.1 inverter, G156HTN02.1 power supply, G156HTN02.1 electronic board, G156HTN02.1 VGA board, G156HTN02.1 touchscreen available.
