Chilin LQ057AC213

Chilin LQ057AC213
#LQ057AC213 Chilin LQ057AC213 New 5.7 inch Resolution 320 x240 Qvga, LQ057AC213 pictures, LQ057AC213 price, #LQ057AC213 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Brand: CHILIN
ModelLQ057AC213
Diagonal Size5.7 inch
Typea-Si TFT-LCD, LCM
Pixel Format320(RGB)×240  [QVGA]
Configuration  RGB Vertical Stripe
Active Area115.2(H)×86.4(V) mm
Outline Dim.126(H)×101.55(V) mm
Bezel Area118.2(H)×89.4(V) mm
TreatmentAntiglare
Luminance300 cd/m² (Typ.)
Contrast Ratio200:1 (Typ.) (TM)
View Direction6 o'clock
Response Time15/35 (Typ.)(Tr/Td)
Viewing Angle60/60/50/55 (Typ.)(CR≥10) Left / Right / Up / Down
Operating ModeTN, Normally White, Transmissive
Support Color262K   50% NTSCLight Source  WLED  [3S7P] , 10K hours , W/O Driver
Weight100g (Typ.)Designed For Automotive Display Industrial
Frame Rate-Touch Panel4-wire Resistive Touch
Interface TypeParallel RGB (1 ch, 6-bit), CCIR601/656 , 50 pins FPC
Power Supply3.3/5.0V (Typ.)(VCC/VDD)
EnvironmentOperating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
LQ057AC213 inverter, LQ057AC213 power supply, LQ057AC213 electronic board, LQ057AC213 VGA board, LQ057AC213 touchscreen available.
