Innolux AT080TN03 V.7

Innolux AT080TN03 V.7
#AT080TN03 V.7 Innolux AT080TN03 V.7 New Innolux 8 inch LCM 800×480 300 300:1 65/65/45/65 262K WLED TTL, AT080TN03 V.7 pictures, AT080TN03 V.7 price, #AT080TN03 V.7 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Brand Innolux
Diagonal Size 8.0 inch
Pixel Format 800(RGB)×480  [WVGA]  116PPI
Active Area 176.64(H)×99.36(V) mm
Bezel Area 180.1(H)×103.4(V) mm
Luminance 300 cd/m² (Typ.)
View Direction 6 o'clock
Viewing Angle 65/65/45/65 (Typ.)(CR≥10)
Support Color 262K
Weight 245g (Typ.)
Frame Rate 60Hz
Type a-Si TFT-LCD , LCM
Configuration RGB Vertical Stripe
Outline Dim. 192.8(H)×116.9(V) ×6.7(D) mm
Treatment Antiglare
Contrast Ratio 300:1 (Typ.) (TM)
Response Time 15/20 (Typ.)(Tr/Td)
Operating Mode TN, Normally White, Transmissive
Light Source WLED  [3S9P] , 20K hours , W/O Driver
Designed For
Touch Panel Without
Interface Type Parallel RGB (1 ch, 6-bit) 60 pins FPC
Power Supply 3.3/10.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C

AT080TN03 V.7 inverter, AT080TN03 V.7 power supply, AT080TN03 V.7 electronic board, AT080TN03 V.7 VGA board, AT080TN03 V.7 touchscreen available.
