Innolux G121X1-L02

Innolux G121X1-L02
Manufacturer ChiMei Innolux. Size 121″. Resolution XGA 1024 x 768. Brightness 500 cd/m². Contrast 700:1 typ. Viewing Angle v/h 160°/160° CR ≥ 10 #G121X1-L02 Innolux G121X1-L02 New CMO G121X1-L02 Datasheet Specification Stocks RFQs Suppliers. a-Si TFT-LCD 12.1' 1024×768 500 nit 700:1 (Typ.) 262K color 60Hz CCFL LVDS., G121X1-L02 pictures, G121X1-L02 price, #G121X1-L02 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Panel Brand : CMO
Panel Model : G121X1-L02
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 12.1 inch
Resolution : 1024(RGB)×768 , XGA
Display Mode : TN, Normally White, Transmissive
Active Area : 245.76×184.32 mm
Outline : 260.5×204×12.2 mm
Surface : Glare (Haze 0%), Hard coating (3H)
Brightness : 500 cd/m² (Typ.)
Contrast Ratio : 700:1 (Typ.)
Display Colors : 262K   (6-bit)
Response Time : 6/17 (Typ.)(Tr/Td)
Viewing Angle : 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
Frequency : 60Hz
Lamp Type : 2 pcs CCFL       Without Driver
Signal Interface : LVDS (1 ch, 6-bit) , 20 pins
Input Voltage : 3.3V (Typ.)


G121X1-L02 inverter, G121X1-L02 power supply, G121X1-L02 electronic board, G121X1-L02 VGA board, G121X1-L02 touchscreen available.
