LG Display LC260W01-A5K4

LG Display LC260W01-A5K4
#LC260W01-A5K4 LG Display LC260W01-A5K4 New LG Display 26 inch LCM 1280×768 450 500:1 88/88/88/88 16.7M CCFL LVDS, LC260W01-A5K4 pictures, LC260W01-A5K4 price, #LC260W01-A5K4 supplier
Email: [email protected]

Panel Brand LG.Philips LCD
Panel Model LC260W01-A5K4
Panel Size 26.0 inch
Panel Type a-Si TFT-LCD , LCM
Resolution 1280(RGB)×768, WXGA, 57PPI
Pixel Format RGB Vertical Stripe
Display Area 566.4(W)×339.84(H) mm
Bezel Opening 571.4(W)×344.9(H) mm
Outline Size 622(W)×389(H) mm
Surface Antiglare, Hard coating (3H)
Brightness 450 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.) (TM)
Viewing Angle 88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode S-IPS, Normally Black, Transmissive
Best View on Symmetry
Response Time 7.5/8.5 (Typ.)(Tr/Td)
Display Colors 16.7M   72% NTSC
Lamp Type 14 pcs CCFL , 50K hours , With Inverter
Frequency 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Screen Without
Panel Weight 5.60/5.80Kgs (Typ./Max.)
Application TV Sets
Signal Interface LVDS (1 ch, 8-bit) , 20 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
LC260W01-A5K4 inverter, LC260W01-A5K4 power supply, LC260W01-A5K4 electronic board, LC260W01-A5K4 VGA board, LC260W01-A5K4 touchscreen available.
