#LM215WF3-SDB1 LG LM215WF3-SDB1 New LM215WF3-SDB1 LG 21.5 Inch LCM 1920×1080 365 1000:1 89/89/89/89 16.7M WLED eDP, LM215WF3-SDB1 pictures, LM215WF3-SDB1 price, #LM215WF3-SDB1 supplier
Email: [email protected]

Panel Brand LG Display
Panel Model LM215WF3-SDB1
Panel Size 21.5"Panel
Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD, 102PPI
Pixel Format RGB Vertical Stripe
Display Area 475.2(W)×267.3(H) mm
Bezel Opening 479.84(W)×272.32(H) mm
Outline Size 495.6(W)×305.25(H) ×15.3(D) mm
Surface Glare (Haze 0%), Hard coating (2H), Antireflection
Brightness 365 cd/m² (Typ.)
Contrast Ratio 1000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode IPS, Normally Black, Transmissive
Best View on Symmetry
Response Time 6.5/7.5 (Typ.)(Tr/Td)
Display Colors 16.7M   100% sRGB
Lamp Type 2 strings WLED , 30K hours , Without Driver
Frequency 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Screen Without
Panel Weight 2.10Kgs (Typ.)ApplicationDesktop Monitor
Signal Interface eDP (4 Lanes) , 30 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
LM215WF3-SDB1 inverter, LM215WF3-SDB1 power supply, LM215WF3-SDB1 electronic board, LM215WF3-SDB1 VGA board, LM215WF3-SDB1 touchscreen available.
