NEC NL10276BC20-18C

NEC NL10276BC20-18C
#NL10276BC20-18C NEC NL10276BC20-18C New NEC 10.4inch LCM 1024×768 800 900:1 80/80/80/80 262K/16.7M WLED LVDS, NL10276BC20-18C pictures, NL10276BC20-18C price, #NL10276BC20-18C supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Panel Brand NEC
Panel Model NL10276BC20-18C
Panel Size 10.4"
Panel Type a-Si TFT-LCD, LCM
Resolution 1024(RGB)×768, XGA, 123PPI
Pixel Format RGB Vertical Stripe
Display Area 210.4(W)×157.8(H) mm
Bezel Opening 215.4(W)×161.8(H) mm
Outline Size 228(W)×178.5(H) ×9.2(D) mm
Surface Clear, Hard coating (2H), Antireflection
Brightness 800 cd/m² (Typ.)
Contrast Ratio 900:1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock
Response Time 3/15 (Typ.)(Tr/Td)
Display Colors 262K/16.7M   40% NTSC
Lamp Type 5 strings WLED , 70K hours , Without Driver
Frequency 60Hz
Touch Screen Without
Panel Weight 380/400g (Typ./Max.)
Application Industrial
Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage 3.3V (Typ.)
Environment Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
NL10276BC20-18C inverter, NL10276BC20-18C power supply, NL10276BC20-18C electronic board, NL10276BC20-18C VGA board, NL10276BC20-18C touchscreen available.
