NEC NL10276BC24-21L

NEC NL10276BC24-21L
#NL10276BC24-21L NEC NL10276BC24-21L New NL10276BC24-21L NLT 12.1 inch LCM 1024×768 450 900:1 80/80/80/80 262K/16.7M WLED LVDS, NL10276BC24-21L pictures, NL10276BC24-21L price, #NL10276BC24-21L supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Panel Brand NEC
Panel Model NL10276BC24-21L
Panel Size 12.1"
Panel Type a-Si TFT-LCD , LCM
Resolution 1024(RGB)×768, XGA, 105PPI
Pixel Format RGB Vertical Stripe
Display Area 245.76(W)×184.32(H) mm
Bezel Opening 249.0(W)×187.5(H) mm
Outline Size 260.5(W)×203(H) ×9.2(D) mm
Surface Clear, Hard coating (3H)
Brightness 450 cd/m² (Typ.)
Contrast Ratio 900:1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode TN, Normally White, Transmissive
IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich
VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA
Best View on 3 o'clock Response Time 3/15 (Typ.)(Tr/Td)
Display Colors 262K/16.7M   40% NTSC
Lamp Type 4 strings WLED , 70K hours , Optional
Frequency 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC
Circuit Touch Screen Without
Panel Weight 490/540g (Typ./Max.)
Application Industrial
Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage 3.3V (Typ.)
Environment Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²)
NL10276BC24-21L inverter, NL10276BC24-21L power supply, NL10276BC24-21L electronic board, NL10276BC24-21L VGA board, NL10276BC24-21L touchscreen available.
