SAMSUNG LMS700KF01-001

SAMSUNG LMS700KF01-001
#LMS700KF01-001 SAMSUNG LMS700KF01-001 New Samsung 7 inch LCM 800×480 280 300:1 65/65/50/60 16.7M WLED TTL, LMS700KF01-001 pictures, LMS700KF01-001 price, #LMS700KF01-001 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Manufacturer SAMSUNG
Model Name LMS700KF01-001
Screen Size 7.0 inch
Screen Type LCM ,   a-Si TFT-LCD
Pixel Number 800×480(RGB)   (WVGA)  133PPI
Arrangement RGB Horizontal Stripe
Active Area(mm) 152.4 × 91.44 (H×V)
Outline(mm) 163.2 × 104 × 4.7 (H×V×D)
Treatment Hard coating (3H)
Luminance 280 cd/m² (Typ.)
Contrast Ratio 300 : 1 (Typ.) (TM)
Viewing Angle 65/65/50/60 (Typ.)(CR≥10) Left / Right / Up / Down
Response 22.7 (Typ.)(Tr+Td) ms
Good View at 6 o'clock
Work Mode TN, Normally White, TMR
Color Depth 16.7M   50% NTSC
Backlight 8S3P WLED , No Driver
Weight 115g (Typ.)
Used for Automotive Display Digital Photo Frame Portable DVD Player VOIP Phone MP3 PMP
Refresh Rate 60Hz
Touchscreen Without
Signal Type Parallel RGB (1 ch, 8-bit) , 40 pins FPC
Voltage Supply 3.3V (Typ.)(VCC)
Max. Ratings Storage Temp.: -30 ~ 70 °C    Operating Temp.: -20 ~ 60 °C
LMS700KF01-001 inverter, LMS700KF01-001 power supply, LMS700KF01-001 electronic board, LMS700KF01-001 VGA board, LMS700KF01-001 touchscreen available.
