SHARP LQ084S3DG01R

SHARP LQ084S3DG01R
#LQ084S3DG01R SHARP LQ084S3DG01R New LQ084S3DG01R Sharp 8.4 inch LCM 800×600 350 250:1 65/65/45/65 262K CCFL TTL, LQ084S3DG01R pictures, LQ084S3DG01R price, #LQ084S3DG01R supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Manufacturer Sharp
Model Name LQ084S3DG01R
Screen Size 8.4 inch
Screen Type LCM,   a-Si TFT-LCD
Pixel Number 800(RGB)×600   (SVGA)  119PPI
Arrangement RGB Vertical Stripe
Active Area(mm) 170.4 × 127.8 (H×V)
Outline(mm) 199.5 × 149.5 (H×V×D)
Bezel Area(mm) 175.15 × 133.1 (H×V)
Luminance 350 cd/m² (Typ.)Contrast Ratio250 : 1 (Typ.) (TM)
Viewing Angle 65/65/45/65 (Typ.)(CR≥5) Left / Right / Up / Down
Response 20/40 (Typ.)(Tr/Td) ms
Good View at 6 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 262K
Backlight 2 pcs CCFL , 50K hours , No Driver
Mass 405g (Max.)Used forIndustrial
Refresh Rate 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touchscreen Without
Signal Type Parallel RGB (1 ch, 6-bit) , 30 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -25 ~ 70 °C    Operating Temp.: -10 ~ 65 °C
LQ084S3DG01R inverter, LQ084S3DG01R power supply, LQ084S3DG01R electronic board, LQ084S3DG01R VGA board, LQ084S3DG01R touchscreen available.
