Sharp LQ121S1DG49

Sharp LQ121S1DG49
#LQ121S1DG49 Sharp LQ121S1DG49 New SHARP 12.1 inch LCD Display Panel, LQ121S1DG49 pictures, LQ121S1DG49 price, #LQ121S1DG49 supplier
-------------------------------------------------------------------
Email: [email protected]

-------------------------------------------------------------------
Brand Sharp
Diagonal Size 12.1 inch
Pixel Format 800(RGB)×600  [SVGA]  82PPI
Active Area 246(H)×184.5(V) mm
Bezel Area 249.0(H)×187.5(V) mm
Luminance 370 cd/m² (Typ.)
View Direction 6 o'clock
Viewing Angle 70/70/50/60 (Typ.)(CR≥10)
Support Color 262K   50% NTSC
Weight 660g (Max.)

Model LQ121S1DG49
Type a-Si TFT-LCD , LCM
Configuration RGB Vertical Stripe
Outline Dim. 276(H)×209(V) ×11(D) mm
Treatment Antiglare, Hard coating (3H)
Contrast Ratio 450:1 (Typ.) (TM)
Response Time 10/25 (Typ.)(Tr/Td)
Operating Mode TN, Normally White, Transmissive
Light Source CCFL  [2 pcs] , 50K hours , W/O Driver
Designed For
Touch Panel Without
nterface Type Parallel RGB (1 ch, 6-bit) 41 pins Connector
Power Supply 3.3/5.0V (Typ.)(VCC)
Environment Operating Temperature: -10 ~ 65 °C ; Storage Temperature: -30 ~ 70 °C

LQ121S1DG49 inverter, LQ121S1DG49 power supply, LQ121S1DG49 electronic board, LQ121S1DG49 VGA board, LQ121S1DG49 touchscreen available.
