Sharp LQ9D340

Sharp LQ9D340
#LQ9D340 Sharp LQ9D340 New SHARP 8.4 inch LCD Display Panel, LQ9D340 pictures, LQ9D340 price, #LQ9D340 supplier
Email: [email protected]

Panel Brand : SHARP
Panel Model : LQ9D340
Panel Type : a-Si TFT-LCD , Panel
Panel Size : 8.4 inch
Resolution : 640(RGB)×480 , VGA
Display Mode : TN, Normally White, Transmissive
Active Area : 170.88×129.6 mm
Outline : 216×152.4 mm
Surface : Clear, Hard coating (2H)
Brightness : 115 cd/m² (Typ.)
Contrast Ratio : 100:1 (Typ.)
Display Colors : 262K   (6-bit)
Response Time : 20/40 (Typ.)(Tr/Td)
Viewing Angle : 50/50/30/50 (Min.)(CR≥10) (L/R/U/D)
Lamp Type : 1 pcs CCFL
Signal Interface : Parallel RGB (1 ch, 6-bit)
Input Voltage : 3.3V (Typ.)(VCC)
LQ9D340 inverter, LQ9D340 power supply, LQ9D340 electronic board, LQ9D340 VGA board, LQ9D340 touchscreen available.
